Özellikleri Fotoğraf Galerisi Ürün Açıklaması Fiyat talebi

Özellikleri

Teknik Özellikler

kova genişliği: 24 inç, 48 inç

Kova Uzunluğu: 1200 mm

Ağırlık: 1000 kg

Uygun ekskavatör: 20ton, 30ton

Kova tipi: standart kova

Malzeme tipi: Q355B, NM400, Hardox500, HG785D

Malzeme Sertliği: 163-187 HB (Q355B), 400 HB (NM400), 470-500 HB (hardox500)

Malzeme uzantısı: % 21 (Q355B),% 16 (NM400),% 8 (hardox500)

Bükülme yoğunluğu: 355 N (Q355B), 1020 N (NM400), 1300 N (hardox500)

Çelik standardı: Avrupa S355JR, Amerikan A57

Çelik tedarikçi: En iyi 3 Çinli çelik üreticisi (CSG)

Pim çapı: Özelleştirilebilir

Pim Merkezi Mesafesi: Özelleştirilebilir

kol genişliği: Özelleştirilebilir

Özel çizim: Tedarik edilen

Vurgulamak:

20-30 ton excavator GP bucket

Q355B steel excavator bucket

excavator rock bucket with warranty

Temel bilgiler

Menşe yeri: Çin

Ödeme & teslimat koşulları

Fotoğraf Galerisi

Standard GP Bucket for 20-30 Ton Excavators Q355B Steel

Ürün Açıklaması

24 Inch Narrow & 48 Inch 1200 mm Standard GP Bucket for 12 Ton Excavator Mini Excavator Bucket

Product Specifications

Attribute	Value
Warranty	1 Year
Weight	1000 kg
Suitable Excavator(ton)	20ton, 30ton
Bucket type	Standard bucket
Machinery Test Report	Provided
Video outgoing-inspection	Provided

Product Description

A general purpose bucket for an excavator is a versatile attachment designed for a wide range of digging and material handling tasks. It is primarily used in construction, landscaping, and earth-moving operations where a single bucket can handle various materials and conditions.

Quality Certification of Steel

We adopted qualified Q355B steel from top 3 Chinese steel maker. Q355B is the most common used material in the industrial, same as European S355JR, American A57.etc.

Moreover, we also offer options using high strength material such as: NM400, Hardox500 and HG785D. All steels are adopted from CSG, top 3 steel maker in China.

Type	Material	Hardness (HB)	Extension (%)	Bend Intensity (N)
Alloy steel	Q355B	163-187	21	355
High Strength steel	NM400	400	16	1020
High Strength steel	Hardox500	470-500	8	1300

How to Choose the Right Bucket

What is your excavator model?
Which type of bucket do you want?
The arm width, pin diameter and pin center to center.

We will make the GA Drawing according to your needs. In order to ensure the perfect size, all products will be produced after you confirm the drawings.
